CM315 32.768KDZC-UT
Crystal, 32.768 kHz, SMD, 3.2mm x 1.5mm, 9 pF, 20 ppm, CM315
Image is for illustrative purposes only. Please refer to product description.
ManufacturerCITIZEN FINEDEVICE
Manufacturer Part NoCM315 32.768KDZC-UT
Order Code2101356RL
Product RangeCM315
Technical Datasheet
1,016 In Stock
Need more?
1016 Delivery in 5-7 Business Days(US stock)
| Quantity | Price |
|---|---|
| 50+ | Rs.146.270 |
| 250+ | Rs.132.020 |
| 500+ | Rs.128.110 |
| 1500+ | Rs.124.200 |
| 3000+ | Rs.116.660 |
Price for:Each (Supplied on Cut Tape)
Minimum: 100
Multiple: 1
Rs.14,627.00
Enter Your Part No/Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
This number will be added to the Order Confirmation, Invoice, Dispatch note, Web confirmation Email and Product Label.
Product Information
ManufacturerCITIZEN FINEDEVICE
Manufacturer Part NoCM315 32.768KDZC-UT
Order Code2101356RL
Product RangeCM315
Technical Datasheet
Frequency Nom32.768kHz
Crystal CaseSMD, 3.2mm x 1.5mm
Frequency Stability + / --
Load Capacitance9pF
Frequency Tolerance + / -20ppm
Product RangeCM315
Operating Temperature Min-40°C
Operating Temperature Max85°C
SVHCNo SVHC (14-Jun-2023)
Product Overview
The CM315 32.768KDZC-UT is a 3.2 x 1.5mm 20ppm surface-mount Crystal Unit features high density, ultra light weight with ultra-miniature and high stability assured with tight vacuum sealing. The CM315 series crystal for portable devices and mobile telecommunications devices applications.
- Tuning fork operation mode
- 70kΩ Maximum motional series resistance
- 1.05pF Typical shunt capacitance
- 1µW Maximum drive level
Applications
Clock & Timing, Portable Devices, Communications & Networking
Technical Specifications
Frequency Nom
32.768kHz
Frequency Stability + / -
-
Frequency Tolerance + / -
20ppm
Operating Temperature Min
-40°C
SVHC
No SVHC (14-Jun-2023)
Crystal Case
SMD, 3.2mm x 1.5mm
Load Capacitance
9pF
Product Range
CM315
Operating Temperature Max
85°C
Alternatives for CM315 32.768KDZC-UT
3 Products Found
Legislation and Environmental
Country of Origin:
Country in which last significant manufacturing process was carried outCountry of Origin:Japan
Country in which last significant manufacturing process was carried out
Country in which last significant manufacturing process was carried outCountry of Origin:Japan
Country in which last significant manufacturing process was carried out
Tariff No:85416000
US ECCN:EAR99
EU ECCN:NLR
RoHS Compliant:Yes
RoHS
RoHS Phthalates Compliant:To be advised
SVHC:No SVHC (14-Jun-2023)
Download Product Compliance Certificate
Product Compliance Certificate
Weight (kg):.00008
