V18MLE0805H

The MLE series Surface Mount Multilayer Metal Oxide Varistor (MOV) is family of transient voltage suppression device, based on the Littelfuse multilayer fabrication technology. This component is designed to suppress ESD events, including those specified in IEC 61000-4-2 or other standards used for Electromagnetic Compliance testing. The MLE series is typically applied to protect integrated circuits and other components at the circuit board level operating at 18VDC or less. The fabrication method and materials of this device result in capacitance characteristics suitable for high frequency attenuation/low-pass filter circuit functions, thereby providing suppression and filtering in a single device. The MLE series is manufactured from semiconducting ceramics and is supplied in a leadless, surface mount package. The MLE series is compatible with modern reflow and wave soldering procedures.

• Halogen-free
• Rated for ESD (IEC-61000-4-2)
• Characterized for impedance and capacitance
• -55 to 125°C Operating temperature range
• Leadless 0402, 0603, 0805 and 1206 sizes
• Operating voltages up to 18VM(DC)
• Multilayer ceramic construction technology

Applications

Safety, Power Management, Motor Drive & Control, Signalling, Consumer Electronics, Computers & Computer Peripherals, Medical, Portable Devices, Industrial
