76-006
Banana Test Connector, 4mm, Plug, Cable Mount, 36 A, 1 kV, Nickel Plated Contacts, Red
Image is for illustrative purposes only. Please refer to product description.
ManufacturerTENMA
Manufacturer Part No76-006
Order Code2667194
Product RangeTUK SGACK902S Keystone Coupler
Technical Datasheet
No Longer Manufactured
Product Information
ManufacturerTENMA
Manufacturer Part No76-006
Order Code2667194
Product RangeTUK SGACK902S Keystone Coupler
Technical Datasheet
Connector MountingCable Mount
Current Rating36A
Voltage Rating1kV
Contact PlatingNickel Plated Contacts
Connector ColourRed
Contact MaterialBeryllium Copper
Contact Termination TypeScrew
Product RangeTUK SGACK902S Keystone Coupler
SVHCLead (10-Jun-2022)
Alternatives for 76-006
1 Product Found
Product Overview
The 76-006 from Tenma is a stacking red banana plug with solderless safety wire termination. It is a 4mm Do-it-Yourself (DIY) stacking sheathed banana plug that allows user to build own test leads and meet the latest safety standards. Solderless set screw wire connection and snap together housing for easy field assembly.
- Insulator body material is polypropylene insulator body
- Brass with nickel plated plug
- BECU with nickel plated contact spring
- Rated voltage is 600V CAT IV / 1000V CAT III and maximum current is 36A
- Internal resistance is less than 10mohm
- Operating temperature is -20°C to +80°C
- Conductor size is 0.09 (12AWG), insulation is 0.16" (4mm) max
- Strip length is 0.25" (6.4mm)
- 12 month limited warranty *view Terms & Conditions for details
Applications
Test & Measurement
Technical Specifications
Gender
Plug
Current Rating
36A
Contact Plating
Nickel Plated Contacts
Contact Material
Beryllium Copper
Product Range
TUK SGACK902S Keystone Coupler
Connector Mounting
Cable Mount
Voltage Rating
1kV
Connector Colour
Red
Contact Termination Type
Screw
SVHC
Lead (10-Jun-2022)
Technical Docs (1)
Associated Products
8 Products Found
Legislation and Environmental
Country of Origin:
Country in which last significant manufacturing process was carried outCountry of Origin:France
Country in which last significant manufacturing process was carried out
Country in which last significant manufacturing process was carried outCountry of Origin:France
Country in which last significant manufacturing process was carried out
Tariff No:85369090
US ECCN:EAR99
EU ECCN:NLR
RoHS Compliant:Y-Ex
RoHS
RoHS Phthalates Compliant:Yes
RoHS
SVHC:Lead (10-Jun-2022)
Download Product Compliance Certificate
Product Compliance Certificate
Weight (kg):.0068
