LP-CC-5

The LP-CC-5 is a LOW-PEAK® 5A 600VAC/300VDC ultimate protection class-CC current-limiting Time-delay Fuse features fast short-circuit protection and dual-element, time-delay provide ultimate protection, reduces existing fuse inventory by up to 33% when upgrading to Low-Peak fuses. Consistent 2:1 ampacity ratios, time-delay characteristic avoids unwanted fuse openings from surge currents while fast response speed under short-circuit conditions provides a high degree of current limitation, current-limitation protects downstream components against damaging thermal and magnetic effects of short-circuit currents, a superior, all-purpose, space-saving branch circuit fuse that meets most protection requirements up to 30A, very compact with rejection tip, proper sizing can provide no damage type-2 coordinated protection for NEMA and IEC motor controllers, superior protection for small horsepower motor circuits. Complies with NEC® section 110.9 for today's large capacity systems.

• 200kA VAC RMS symmetrical, 20kA VDC Interrupting rating

Applications

Safety, Motor Drive & Control
