Our range of sensor connectors includes male connectors, female connectors, and sensor cables

Types of sensor connector

The primary use of such connectors is to create complex automated systems, but the variety of processes that employ them creates demand for different variants. These range from uses such as simple digital commands, to heavy-duty data and power transfer.

The connectors are easy to differentiate due to their visual features and simple coding system. This means understanding which one to use under any circumstance is mostly fool-proof and practical. Key sensor connector coding and applications are summarised here (Other codes are available):

A-coded: A variety of sensors, actuators, and motors
B-coded: Network cables for Fieldbus
C-coded: AC sensors and actuators
D-coded: High-speed data transfer up to 100Mbps for network cables
X-coded: High-speed data transfer to 10Gbps
S-Coded: Newer variant of C-coded
T-coded: Newer variant of A-coded

Manufacturer Part No	Order Code	Manufacturer / Description	Price For	Price	Product Range	Shell Type	Sensor Connector Size	Accessory Type	Circular Connector Shell Style	For Use With	Sensor Connector Gender	No. of Contacts	Circular Connector Contact Type	Cable Length - Metric	No. of Positions	Coupling Style	Cable Length - Imperial	Sensor Contact Type	Sensor Connector Mounting	IP / NEMA Rating	Operating Temperature Range	Connector Coding	Connector Body Material	Contact Material	Contact Plating	Current Rating	Voltage Rating

Q8U-06BFFA-QL8001	3703673 RoHS	AMPHENOL LTW Sensor Connector HS-Lok Series Q8 Female 6 Positions Solder Socket Straight Cable Mount	Each	1+Rs.1,876.620 10+Rs.1,594.650 25+Rs.1,475.100 100+Rs.1,355.540 250+Rs.1,270.750 More Pricing...	HS-Lok Series	-	Q8	-	-	-	Female	-	-	-	6 Positions	-	-	Solder Socket	Straight Cable Mount	IP68	-	-	Thermoplastic Body	Copper Alloy	Gold	2A	100V
T4142012031-000	2723643 Data Sheet RoHS	TE CONNECTIVITY Sensor Connector M12 Male 3 Positions PCB Pin Straight Panel Mount	Each	1+Rs.766.540 10+Rs.655.510 100+Rs.561.360 250+Rs.527.970 500+Rs.504.120 More Pricing...	-	-	M12	-	-	-	Male	-	-	-	3 Positions	-	-	PCB Pin	Straight Panel Mount	IP67	-	A Coded	Copper Alloy Body	Copper Alloy	Gold	4A	250V
1506752	2308651 Data Sheet RoHS	PHOENIX CONTACT Sensor Connector Piercecon Series M8 Male 3 Positions Straight Cable Mount	Each	1+Rs.2,212.710 10+Rs.2,168.460 25+Rs.2,124.210 100+Rs.2,079.950 250+Rs.2,049.330	Piercecon Series	-	M8	-	-	-	Male	-	-	-	3 Positions	-	-	-	Straight Cable Mount	IP68	-	A Coded	Nylon 6.6 (Polyamide 6.6) Body	Brass	Gold	4A	60V
120084-0032	2080768 Data Sheet RoHS	MOLEX Sensor Connector BRAD Ultra-Lock 120084 Series M12 Female 8 Positions PCB Socket	Each	1+Rs.1,814.610 10+Rs.1,778.320 25+Rs.1,742.030 100+Rs.1,705.740 250+Rs.1,669.450 More Pricing...	Ultra-Lock 120084 Series	-	M12	-	-	-	Female	-	-	-	8 Positions	-	-	PCB Socket	Straight Panel Mount	IP67, IP68, IP69K	-	-	Brass Body	Brass	Gold	2A	36VDC
1694282	2544707 Data Sheet RoHS	PHOENIX CONTACT Sensor Connector IP67 Right Angle M12 Male 5 Positions Screw Pin Right Angle Cable Mount	Each	1+Rs.3,182.620 5+Rs.3,118.970 10+Rs.3,055.320 25+Rs.2,991.670 50+Rs.2,928.020	-	-	M12	-	-	-	Male	-	-	-	5 Positions	-	-	Screw Pin	Right Angle Cable Mount	IP67	-	A Coded	Nylon (Polyamide) Body	Brass	Gold	4A	60V
MA2LAE1600	2806651 Data Sheet RoHS	AMPHENOL SINE/TUCHEL Sensor Connector MotionGrade M23 Standard Series M23 Female 16 Positions Crimp Socket	Each	1+Rs.1,029.870 10+Rs.879.380 100+Rs.787.670 250+Rs.716.670 500+Rs.683.710 More Pricing...	MotionGrade M23 Standard Series	-	M23	-	-	-	-	-	-	-	16 Positions	-	-	Crimp Socket	Straight Panel Mount	IP67	-	-	Zinc Body	-	-	9A	125V
MA1LAE1600	2806654 Data Sheet RoHS	AMPHENOL SINE/TUCHEL Sensor Connector MotionGrade M23 Standard Series M23 Female 16 Positions	Each	1+Rs.1,276.050 10+Rs.1,116.550 100+Rs.925.140 250+Rs.829.440 500+Rs.765.630 More Pricing...	MotionGrade M23 Standard Series	-	M23	-	-	-	Female	-	-	-	16 Positions	-	-	Crimp Socket - Contacts Not Supplied	Straight Panel Mount	IP67	-	-	Nylon 6.6 (Polyamide 6.6) Body, Zinc Alloy Body	Brass	Gold	9A	125V
MSDS-04PMMT-EE0001	2911995 Data Sheet RoHS	AMPHENOL LTW Sensor Connector M Series M12 Male 4 Positions PCB Pin Straight Panel Mount	Each	1+Rs.481.830 10+Rs.412.270 100+Rs.370.190 250+Rs.362.790 500+Rs.355.390 More Pricing...	M Series	-	M12	-	-	-	Male	-	-	-	4 Positions	-	-	PCB Pin	Straight Panel Mount	IP65, IP68	-	D Coded	Glass Filled Nylon (Polyamide), Zinc Alloy Body	Copper Alloy	Gold	4A	250V
MPM12-SSP-3AFP	3126347 Data Sheet RoHS	MULTICOMP PRO Sensor Connector M12 Male 3 Positions Solder Pin Straight Panel Mount	Each	1+Rs.654.220 5+Rs.555.150 10+Rs.506.880 25+Rs.468.770	-	-	M12	-	-	-	-	-	-	-	3 Positions	-	-	Solder Pin	Straight Panel Mount	IP67	-	A Coded	Brass Body	Brass	Gold	4A	250V
M12D-04PFFS-SH8001	2707996 Data Sheet RoHS	AMPHENOL LTW Sensor Connector 4 Pole M12 Receptacle M Series M12 Female 4 Positions Solder Socket	Each	1+Rs.718.290 10+Rs.651.410 100+Rs.561.610 250+Rs.544.410 500+Rs.506.190 More Pricing...	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Copper Alloy	-	4A	250V
120071-0041	2918381 Data Sheet RoHS	MOLEX Sensor Connector BRAD Micro-Change Micro-Change 120071 Series M12 Female 5 Positions	Each	1+Rs.3,419.850 10+Rs.3,095.980 25+Rs.2,975.600 100+Rs.2,885.800 250+Rs.2,774.020 More Pricing...	Micro-Change 120071 Series	-	M12	-	-	-	Female	-	-	-	5 Positions	-	-	Solder Socket	Straight Cable Mount	IP67	-	-	Nylon (Polyamide) Body	Copper Alloy	Silver	4A	36VDC
C115 E05 041 G1	2806643 Data Sheet RoHS	AMPHENOL SINE/TUCHEL Sensor Connector x mate Series M15 Female 6 Positions Crimp Socket Straight Panel Mount	Each	1+Rs.395.830 10+Rs.346.140 100+Rs.314.830 250+Rs.300.400 500+Rs.291.930 More Pricing...	x mate Series	-	M15	-	-	-	Female	-	-	-	6 Positions	-	-	Crimp Socket	Straight Panel Mount	IP67	-	-	Nylon (Polyamide) Body	-	Silver	10A	63V
MPM12-SSS-3ARP	3126360 Data Sheet RoHS	MULTICOMP PRO Sensor Connector M12 Female 3 Positions Solder Socket Straight Panel Mount	Each	1+Rs.668.740 5+Rs.568.390 10+Rs.517.580 25+Rs.480.750	-	-	M12	-	-	-	-	-	-	-	3 Positions	-	-	Solder Socket	Straight Panel Mount	IP67	-	A Coded	Brass Body	Brass	Gold	4A	250V
1553611	3269575 Data Sheet RoHS	PHOENIX CONTACT Sensor Connector M12 Female 4 Positions IDC / IDT Socket Straight Cable Mount	Each	1+Rs.2,936.920 5+Rs.2,878.190 10+Rs.2,819.450 25+Rs.2,760.710 50+Rs.2,701.970	-	-	M12	-	-	-	Female	-	-	-	4 Positions	-	-	IDC / IDT Socket	Straight Cable Mount	IP67	-	D Coded	Zinc Body	Bronze	Gold	1.75A	60V
MSAP-08BFFA-SL8001	3372891 RoHS	AMPHENOL LTW Sensor Connector M Series M12 Female 8 Positions Screw Socket Straight Cable Mount	Each	1+Rs.1,166.170 10+Rs.997.040 25+Rs.925.460 100+Rs.853.880 250+Rs.803.110 More Pricing...	M Series	-	M12	-	-	-	Female	-	-	-	8 Positions	-	-	Screw Socket	Straight Cable Mount	IP68	-	A Coded	Nylon (Polyamide), Glass Filled Body	Copper Alloy	Gold	2A	30V
T4140L12041-000	3281082 Data Sheet RoHS	TE CONNECTIVITY Sensor Connector M12 Male 3P + PE Positions PCB Pin Straight Panel Mount	Each	1+Rs.1,057.930 10+Rs.905.910 25+Rs.851.920 100+Rs.776.630 250+Rs.730.790 More Pricing...	-	-	M12	-	-	-	Male	-	-	-	3P + PE Positions	-	-	PCB Pin	Straight Panel Mount	IP67	-	L Coded	Copper Alloy Body	Copper Alloy	Gold	16A	63V
120070-5178	3498114 RoHS	MOLEX Sensor Connector 120070 Series M12 Female 8 Positions PCB Socket Straight Panel Mount	Each	1+Rs.1,711.920 10+Rs.1,494.740 25+Rs.1,357.870 100+Rs.1,294.830 250+Rs.1,257.800 More Pricing...	120070 Series	-	M12	-	-	-	Female	-	-	-	8 Positions	-	-	PCB Socket	Straight Panel Mount	-	-	-	-	-	-	-	-
120070-5170	3498113 RoHS	MOLEX Sensor Connector 120070 Series M12 Female 5 Positions PCB Socket Straight Panel Mount	Each	1+Rs.997.980 10+Rs.871.370 100+Rs.791.580 250+Rs.754.830 500+Rs.733.240 More Pricing...	120070 Series	-	M12	-	-	-	Female	-	-	-	5 Positions	-	-	PCB Socket	Straight Panel Mount	-	-	-	-	-	-	-	-
PXMBNI12RAF08APCM12	3678814 Data Sheet RoHS	BULGIN LIMITED Sensor Connector PXM Series M12 Female 8 Positions PCB Socket Right Angle Panel Mount	Each	1+Rs.4,620.340 5+Rs.4,198.070 10+Rs.3,775.790 25+Rs.3,644.900 50+Rs.3,571.330 More Pricing...	PXM Series	-	M12	-	-	-	Female	-	-	-	8 Positions	-	-	PCB Socket	0	IP67	-	A Coded	Brass Body	Phosphor Bronze	Gold	2A	30V
M8S-06PMMT-EE0001	3703773 RoHS	AMPHENOL LTW Sensor Connector M Series M8 Male 6 Positions PCB Pin Straight PCB Mount	Each	1+Rs.526.000 10+Rs.450.610 100+Rs.404.630 250+Rs.396.540 500+Rs.388.450 More Pricing...	M Series	-	M8	-	-	-	Male	-	-	-	6 Positions	-	-	PCB Pin	Straight PCB Mount	-	-	-	Thermoplastic Body	Copper Alloy	Gold	1.5A	30V
PXPLCP12SMM04APC	3678867 Data Sheet RoHS	BULGIN LIMITED Sensor Connector PXP Series M12 Male 4 Positions PCB Pin Straight Surface Mount	Each	1+Rs.3,857.180 5+Rs.3,577.600 10+Rs.3,298.020 25+Rs.2,920.580 50+Rs.2,543.140 More Pricing...	PXP Series	-	M12	-	-	-	Male	-	-	-	4 Positions	-	-	PCB Pin	Straight Surface Mount	IP67	-	A Coded	LCP (Liquid Crystal Polymer) Body	Brass	Gold	4A	250V
M12A-05BMMA-SR7001	4340968 RoHS	AMPHENOL LTW Sensor Connector M Series M12 Male 5 Positions Solder Pin Right Angle Cable Mount	Each	1+Rs.969.820 10+Rs.832.800 100+Rs.716.590 250+Rs.683.710 500+Rs.650.830 More Pricing...	M Series	-	M12	-	-	-	Male	-	-	-	5 Positions	-	-	Solder Pin	Right Angle Cable Mount	IP67	-	A Coded	Thermoplastic Body	Copper Alloy	Gold	4A	-
PXPTPU78RAF04ASTM22	4305669 Data Sheet RoHS	BULGIN LIMITED Sensor Connector Buccaneer Series 7/8" Female 4 Positions Screw Socket	Each	1+Rs.5,198.220 5+Rs.4,808.770 10+Rs.4,419.310 25+Rs.4,187.430 50+Rs.4,186.480 More Pricing...	Buccaneer Series	-	7/8"	-	-	-	Female	-	-	-	4 Positions	-	-	Screw Socket	Right Angle Cable Mount	IP67	-	A Coded	TPU (Thermoplastic Polyurethane) Body	Phosphor Bronze	Gold	9A	300V
MP011271	4141825 Data Sheet RoHS	MULTICOMP PRO Sensor Connector PG7 MP Field Installable Sensor Connectors M12 Female 5 Positions	Each	1+Rs.2,048.860 5+Rs.1,853.250 10+Rs.1,733.850 25+Rs.1,615.720	MP Field Installable Sensor Connectors	-	M12	-	-	-	-	-	-	-	5 Positions	-	-	Screw Socket	Straight Cable Mount	IP67	-	A Coded	Brass Body	Brass	Gold	4A	60V
M12A-03PFFR-EE0001	4061215 Data Sheet RoHS	AMPHENOL LTW Sensor Connector M Series M12 Female 3 Positions PCB Socket Right Angle PCB Mount	Each	1+Rs.575.690 10+Rs.492.180 100+Rs.424.270 250+Rs.412.860 500+Rs.394.090 More Pricing...	M Series	-	M12	-	-	-	Female	-	-	-	3 Positions	-	-	PCB Socket	Right Angle PCB Mount	-	-	A Coded	Thermoplastic Body	Copper Alloy	Gold	-	-
