Farnell offers flexible PC‑based oscilloscopes that leverage computer interfacing to deliver powerful waveform capture, analysis and reporting. These instruments are well suited for research labs, development benches and automated test environments where rich software features are needed alongside precise signal acquisition.

PC‑based oscilloscopes comprise external hardware modules that connect to a computer via USB or network. The host PC provides processing, display, storage and analysis capabilities, while the external module acquires and conditions electrical signals. With advanced software suites, users can perform waveform visualization, measurement parameter extraction, automated testing and long‑term data logging - all with the familiar power of a desktop or laptop interface.

Applications

Laboratory waveform analysis
Automated data acquisition and reporting
Design validation and prototyping
Education and training environments

Manufacturer Part No	Order Code	Manufacturer / Description	Price For	Price	Product Range	Scope Channels	Bandwidth	Sampling Rate	Display Memory Depth	Calculated Rise Time	Kit Contents	Manufacturer Warranty	Plug Type

PICOSCOPE 3206D MSO	2432910 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope PicoScope 3000 Series 2+16 Channel 200 MHz 1 GSPS 512 Mpts 1.75 ns	Each	1+Rs.229,171.620	PicoScope 3000 Series	2+16 Channel	200MHz	1GSPS	512 Mpts	1.75ns	PicoScope 3206D MSO, TA386 One 200 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA136 Digital Interface Cable, TA139 Digital Test Clips 8 x Red, 2 x Black, Pack of 10, TA155 USB3 Cable, 1.8m, PS011 AC Power Adaptor 5V, Quick Start Guide	5 Years	USB
PICOSCOPE 2205A	2365426 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope PicoScope 2000 Series 2 Channel 25 MHz 200 MSPS 16 kpts 14 ns	Each	1+Rs.25,953.760	PicoScope 2000 Series	2 Channel	25MHz	200MSPS	16 kpts	14ns	PicoScope 2205A, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA207 USB2 Cable, 1.2m, TA208 Twin Pack of Probes, Quick Start Guide	5 Years	USB
PICOSCOPE 2204A	2365425 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope PicoScope 2000 Series 2 Channel 10 MHz 100 MSPS 8 kpts 35 ns	Each	1+Rs.17,948.870	-	-	-	-	-	-	-	-	-
PICOSCOPE 3403D MSO	2460220 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope PicoScope 3000 Series 4+16 Channel 50 MHz 1 GSPS 64 Mpts 7 ns	Each	1+Rs.178,701.280	PicoScope 3000 Series	4+16 Channel	50MHz	1GSPS	64 Mpts	7ns	PicoScope 3403D MSO, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA136 Digital Interface Cable, TA139 Digital Test Clips 8 x Red, 2 x Black, Pack of 10, TA155 USB3 Cable, 1.8m, PS011 AC Power Adaptor 5V, Quick Start Guide	5 Years	USB
PICOSCOPE 2207B	2535475 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope Digital Triggering PicoScope 2000 Series 2 Channel 70 MHz 1 GSPS 64 Mpts	Each	1+Rs.58,298.770	PicoScope 2000 Series	2 Channel	70MHz	1GSPS	64 Mpts	5ns	PicoScope 2207B, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA207 USB2 Cable, 1.2m, Quick Start Guide	-	USB
PICOSCOPE 2204A-D2	2432914 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope No Probes PicoScope 2000 Series 2 Channel 10 MHz 100 MSPS 8 kpts 35 ns	Each	1+Rs.14,958.270	PicoScope 2000 Series	2 Channel	10MHz	100MSPS	8 kpts	35ns	PicoScope 2204A-D2, TA207 USB2 Cable, 1.2m, Quick Start Guide (Probes not Supplied)	5 Years	USB
PICOSCOPE 2208B	2535476 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope Digital Triggering PicoScope 2000 Series 2 Channel 100 MHz 1 GSPS	Each	1+Rs.80,041.870	PicoScope 2000 Series	2 Channel	100MHz	1GSPS	128 Mpts	3.5ns	PicoScope 2208B, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA207 USB2 Cable, 1.2m, Quick Start Guide	-	USB
PICOSCOPE 2408B	2535479 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope Digital Triggering PicoScope 2000 Series 4 Channel 100 MHz 1 GSPS	Each	1+Rs.130,322.510	PicoScope 2000 Series	4 Channel	100MHz	1GSPS	128 Mpts	3.5ns	PicoScope 2408B, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA207 USB2 Cable, 1.2m, Quick Start Guide	-	USB
PICOSCOPE 3203D MSO	2460215 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope PicoScope 3000 Series 2+16 Channel 50 MHz 1 GSPS 64 Mpts 7 ns	Each	1+Rs.151,839.300	PicoScope 3000 Series	2+16 Channel	50MHz	1GSPS	64 Mpts	7ns	PicoScope 3203D MSO, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA136 Digital Interface Cable, TA139 Digital Test Clips 8 x Red, 2 x Black, Pack of 10, TA155 USB3 Cable, 1.8m, PS011 AC Power Adaptor 5V, Quick Start Guide	5 Years	USB
PICOSCOPE 2205A MSO	2535473 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope Digital Triggering PicoScope 2000 Series 2+16 Channel 25 MHz 200 MSPS	Each	1+Rs.52,862.980	PicoScope 2000 Series	2+16 Channel	25MHz	200MSPS	16 kpts	14ns	PicoScope 2205A MSO, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA207 USB2 Cable, 1.2m, TA208 Twin Pack of Probes, TA136 Digital Interface Cable, TA139 Digital Test Clips 8 x Red, 2 x Black, Pack of 10, Quick Start Guide	-	USB
PICOSCOPE 2405A	2535471 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope Digital Triggering PicoScope 2000 Series 4 Channel 25 MHz 500 MSPS	Each	1+Rs.58,392.830	PicoScope 2000 Series	4 Channel	25MHz	500MSPS	48 kpts	14ns	PicoScope 2405A, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA207 USB2 Cable, 1.2m, Quick Start Guide	-	USB
PICOSCOPE 2206B	2535474 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope Digital Triggering PicoScope 2000 Series 2 Channel 50 MHz 500 MSPS	Each	1+Rs.43,350.370	PicoScope 2000 Series	2 Channel	50MHz	500MSPS	32 Mpts	7ns	PicoScope 2206B, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA207 USB2 Cable, 1.2m, Quick Start Guide	-	USB
PICOSCOPE 3405D MSO	2432912 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope MSO PicoScope 3000 Series 4+16 Channel 100 MHz 1 GSPS 256 Mpts 3.5 ns	Each	1+Rs.243,930.630	PicoScope 3000 Series	4+16 Channel	100MHz	1GSPS	256 Mpts	3.5ns	PicoScope 3405D MSO, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA136 Digital Interface Cable, TA139 Digital Test Clips 8 x Red, 2 x Black, Pack of 10, TA155 USB3 Cable, 1.8m, PS011 AC Power Adaptor 5V, Quick Start Guide	5 Years	USB
PICOSCOPE 3404D MSO	2432911 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope PicoScope 3000 Series 4+16 Channel 70 MHz 1 GSPS 128 Mpts 5.8 ns	Each	1+Rs.209,957.010	PicoScope 3000 Series	4+16 Channel	70MHz	1GSPS	128 Mpts	5.8ns	PicoScope 3404D MSO, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA136 Digital Interface Cable, TA139 Digital Test Clips 8 x Red, 2 x Black, Pack of 10, TA155 USB3 Cable, 1.8m, PS011 AC Power Adaptor 5V, Quick Start Guide	5 Years	USB
PICOSCOPE 3204D MSO	2432908 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope PicoScope 3000 Series 2+16 Channel 70 MHz 1 GSPS 128 Mpts 5.8 ns	Each	1+Rs.169,188.670	PicoScope 3000 Series	2 Channel	100MHz	1GSPS	25 kpts	3.5ns	Oscilloscope, 2x Probe (1x, 10x Switchable), Power Cord , USB Cable, PC Software, Manual	1 Year	-
PICOSCOPE 2406B	2535477 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope Digital Triggering PicoScope 2000 Series 4 Channel 50 MHz 1 GSPS 32 Mpts	Each	1+Rs.67,811.380	PicoScope 2000 Series	4 Channel	50MHz	1GSPS	32 Mpts	7ns	PicoScope 2406B, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA207 USB2 Cable, 1.2m, Quick Start Guide	-	USB
PICOSCOPE 3406D MSO	2432913 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope MSO PicoScope 3000 Series 4+16 Channel 200 MHz 1 GSPS 512 Mpts 1.75 ns	Each	1+Rs.291,493.710	PicoScope 3000 Series	4+16 Channel	200MHz	1GSPS	512 Mpts	1.75ns	PicoScope 3406D MSO, TA386 One 200 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA136 Digital Interface Cable, TA139 Digital Test Clips 8 x Red, 2 x Black, Pack of 10, TA155 USB3 Cable, 1.8m, PS011 AC Power Adaptor 5V, Quick Start Guide	5 Years	USB
PICOSCOPE 2205A-D2	2460225 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope No Probes PicoScope 2000 Series 2 Channel 25 MHz 200 MSPS 16 kpts 14 ns	Each	1+Rs.21,328.840	PicoScope 2000 Series	2 Channel	25MHz	200MSPS	16 kpts	14ns	PicoScope 2205A-D2, TA207 USB2 Cable, 1.2m, Quick Start Guide (Probes not Supplied)	5 Years	USB
PICOSCOPE 2208B MSO	2535482 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope Digital Triggering PicoScope 2000 Series 2+16 Channel 100 MHz 1 GSPS	Each	1+Rs.114,015.510	PicoScope 2000 Series	2+16 Channel	100MHz	1GSPS	128 Mpts	3.5ns	PicoScope 2208B MSO, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, TA207 USB2 Cable, 1.2m, TA136 Digital Interface Cable, TA139 Digital Test Clips 8 x Red, 2 x Black, Pack of 10, Quick Start Guide	-	USB
PICOSCOPE 4444 SCOPE ONLY	2748597 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope PicoScope 4000 Series 4 Channel 20 MHz 50 MSPS 256 Mpts 17.5 ns	Each	1+Rs.151,522.390	-	-	-	-	-	-	-	-	-
PICOSCOPE 5443D	2893191 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope FlexRes PicoScope 5000D Series 4 Channel 100 MHz 1 GSPS 512 Mpts 3.5 ns	Each	1+Rs.265,673.750	PicoScope 5000D Series	4 Channel	100MHz	1GSPS	512 Mpts	3.5ns	PicoScope 5243D, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, MI106 USB2 Cable, 1.8m, TA146 USB2 Double Headed Cable, PS011 AC Power Adaptor 5V, Quick Start Guide	5 Years	USB
PICOSCOPE 5244D MSO	2893195 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope FlexRes PicoScope 5000D 2 Analogue 16 Digital 200 MHz 1 GSPS 512 Mpts	Each	1+Rs.261,596.920	PicoScope 5000D Series	2 Analogue, 16 Digital	200MHz	1GSPS	512 Mpts	1.75ns	PicoScope 5244D MSO, TA386 One 200 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, MI106 USB2 Cable, 1.8m, TA146 USB2 Double Headed Cable, Quick Start Guide	5 Years	USB
PICOSCOPE 5443D MSO	2893197 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope FlexRes PicoScope 5000D Series 4 Analogue 16 Digital 100 MHz 1 GSPS	Each	1+Rs.296,929.480	PicoScope 5000D Series	4 Analogue, 16 Digital	100MHz	1GSPS	512 Mpts	3.5ns	PicoScope 5243D MSO, TA375 One 100 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, MI106 USB2 Cable, 1.8m, TA146 USB2 Double Headed Cable, PS011 AC Power Adaptor 5V, Quick Start Guide	5 Years	USB
PICOSCOPE 5444D	2893192 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope MSO PicoScope 5000D Series 4 Channel 200 MHz 1 GSPS 512 Mpts 1.75 ns	Each	1+Rs.320,031.560	PicoScope 5000D Series	4 Channel	200MHz	1GSPS	512 Mpts	1.75ns	PicoScope 5244D, TA386 One 200 MHz Passive Probe Per Channel 1:1, 10:1 Switchable, BNC, MI106 USB2 Cable, 1.8m, TA146 USB2 Double Headed Cable, PS011 AC Power Adaptor 5V, Quick Start Guide	5 Years	USB
PICOSCOPE 4444 1000 V KIT	2748594 Data Sheet RoHS	PICO TECHNOLOGY PC USB Oscilloscope PicoScope 4000 Series 4 Channel 10 MHz 50 MSPS 256 Mpts 35 ns	Each	1+Rs.228,982.230	PicoScope 4000 Series	4 Channel	10MHz	50MSPS	256 Mpts	35ns	PicoScope 4444 1000 V CAT III KIT, Differential Osc With 3 PicoConnect 442 25:1 Differential Voltage Probes & One TA271 D9-BNC Adaptor	-	-
