| Manufacturer | TE CONNECTIVITY - AMP |
|---|---|
| Manufacturer Part No | 2199119-3Copy |
| Manufacturer Standard Lead Time | 14 weeks |
| Order Code | Full Reel2377492 Cut Tape2377471 |
| Product Range | M.2 (NGFF) |
| Your Part Number | |
| Technical Datasheet |
Need more?
| Packaging Type | Quantity | Unit Price: | Total |
|---|---|---|---|
| Cut Tape | 1 | Rs.215.160 | Rs.215.16 |
| Total Price | Rs.215.16 | ||
| Quantity | Price |
|---|---|
| 1+ | Rs.215.160 |
| 30+ | Rs.172.260 |
| 90+ | Rs.164.330 |
| 240+ | Rs.156.770 |
| 600+ | Rs.140.560 |
| Quantity | Price |
|---|---|
| 1200+ | Rs.128.540 |
| 3600+ | Rs.119.280 |
Product Information
| Manufacturer | TE CONNECTIVITY - AMP |
|---|---|
| Manufacturer Part No | 2199119-3Copy |
| Manufacturer Standard Lead Time | 14 weeks |
| Order Code | Full Reel2377492 Cut Tape2377471 |
| Product Range | M.2 (NGFF) |
| Technical Datasheet | |
| Card Edge Connector Type | Dual Side |
| Card Thickness | - |
| No. of Contacts | 67 Contacts |
| Connector Mounting | Surface Mount |
| Connector Body Orientation | Right Angle |
| Contact Termination Type | Solder |
| Contact Material | Copper Alloy |
| Contact Plating - Mating Side | 15µ" Gold Plated Contacts |
| Connector Body Material | Thermoplastic Body |
| Product Range | M.2 (NGFF) |
| SVHC | No SVHC (04-Feb-2026) |
Product Overview
The M.2 (NGFF) series M.2 Connector supports multiple function add-in cards and modules including WiFi, Bluetooth, global navigation satellite systems, near field communication, hybrid digital radio, wireless gigabit alliance (WiGig), wireless wide area network and solid-state storage devices. It also adds functionality to PCIe Gen 3, SATA 3, SATA I/O and USB 3.0. The new, smaller form factor is suitable for applications in new thin platforms. The M.2 next generation form factor (NGFF) product line is a natural transition from the mini card and half mini card to a smaller form factor in both size and volume.
- Available in various heights
- Designed for both single and double-sided modules
- Available in various keying options for module cards
- Support PCI Express 3.0, USB 3.0 and SATA 3.0
- Save more than 20% PCB real estate compare to PCIe mini card
- Reduces connector height by 15%
- Ensures proper mating with various modules cards
- Supports higher data rate
Applications
Wireless, Computers & Computer Peripherals, Communications & Networking, Portable Devices, Consumer Electronics
Technical Specifications
| Card Edge Connector Type | Dual Side |
|---|---|
| No. of Contacts | 67 Contacts |
| Connector Body Orientation | Right Angle |
| Contact Material | Copper Alloy |
| Connector Body Material | Thermoplastic Body |
| SVHC | No SVHC (04-Feb-2026) |
| Card Thickness | - |
|---|---|
| Connector Mounting | Surface Mount |
| Contact Termination Type | Solder |
| Contact Plating - Mating Side | 15µ" Gold Plated Contacts |
| Product Range | M.2 (NGFF) |
Technical Docs (3)
Legislation and Environmental
| Country of Origin: Country in which last significant manufacturing process was carried outCountry of Origin: | China Country in which last significant manufacturing process was carried out |
|---|---|
| Tariff No: | 85369090 |
| US ECCN: | EAR99 |
| EU ECCN: | NLR |
| RoHS Compliant: | Yes RoHS |
| RoHS Phthalates Compliant: | Yes RoHS |
| SVHC: | No SVHC (04-Feb-2026) |
| Download Product Compliance Certificate | Product Compliance Certificate |
| Weight (kg): | .001089 |
