CRM2512-JW-1R0ELF
SMD Current Sense Resistor, 1 ohm, CRM Series, 2512 [6432 Metric], 2 W, ± 5%, Thick Film
Image is for illustrative purposes only. Please refer to product description.
![BOURNS CRM2512-JW-1R0ELF SMD Current Sense Resistor, 1 ohm, CRM Series, 2512 [6432 Metric], 2 W, ± 5%, Thick Film](https://in.element14.com/productimages/standard/en_GB/60058365.jpg)
ManufacturerBOURNS
Manufacturer Part NoCRM2512-JW-1R0ELFCopy
Manufacturer Standard Lead Time16 weeks
Order Code
Full Reel4158433
Re-Reel1865268RL
Cut Tape1865268
Product RangeCRM Series
Your Part Number
40,811 In Stock
Need more?
40,811 Delivery in 4-6 Business Days(UK stock)
Packaging Options
| Packaging Type | Quantity | Unit Price: | Total |
|---|---|---|---|
| Cut Tape | 10 | Rs.27.330 | Rs.273.30 |
| Total Price | Rs.273.30 | ||
Cut Tape & Re-Reel
| Quantity | Price |
|---|---|
| 10+ | Rs.27.330 |
| 100+ | Rs.17.360 |
| 500+ | Rs.13.840 |
| 1000+ | Rs.12.790 |
| 2000+ | Rs.12.540 |
Full Reel
| Quantity | Price |
|---|---|
| 4000+ | Rs.10.980 |
| 20000+ | Rs.10.230 |
| 40000+ | Rs.10.030 |
Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
Product Information
ManufacturerBOURNS
Manufacturer Part NoCRM2512-JW-1R0ELFCopy
Manufacturer Standard Lead Time16 weeks
Order Code
Full Reel4158433
Re-Reel1865268RL
Cut Tape1865268
Product RangeCRM Series
Technical Datasheet
Resistance1ohm
Product RangeCRM Series
Resistor Case / Package2512 [6432 Metric]
Power Rating2W
Resistance Tolerance± 5%
Resistor TechnologyThick Film
Temperature Coefficient± 200ppm/°C
Product Length6.3mm
Product Width3.1mm
Product Height0.6mm
Operating Temperature Min-55°C
Operating Temperature Max155°C
Qualification-
SVHCNo SVHC (04-Feb-2026)
Product Overview
The CRM2512-JW-1R0ELF is a SMD high power current sense Chip Resistor with thick film technology. The power resistor with a rating of 2W in a standard 2512 chip formats. This resistor has a very wide resistance range making it suitable for different applications in power supply circuits including current sensing and current limiting.
- Tin-plated termination
- -55 to 155°C Operating temperature range
Technical Specifications
Resistance
1ohm
Resistor Case / Package
2512 [6432 Metric]
Resistance Tolerance
± 5%
Temperature Coefficient
± 200ppm/°C
Product Width
3.1mm
Operating Temperature Min
-55°C
Qualification
-
Product Range
CRM Series
Power Rating
2W
Resistor Technology
Thick Film
Product Length
6.3mm
Product Height
0.6mm
Operating Temperature Max
155°C
SVHC
No SVHC (04-Feb-2026)
Alternatives for CRM2512-JW-1R0ELF
1 Product Found
Associated Products
2 Products Found
Legislation and Environmental
Country of Origin:
Country in which last significant manufacturing process was carried outCountry of Origin:Taiwan
Country in which last significant manufacturing process was carried out
Country in which last significant manufacturing process was carried outCountry of Origin:Taiwan
Country in which last significant manufacturing process was carried out
Tariff No:85332919
US ECCN:EAR99
EU ECCN:NLR
RoHS Compliant:Y-Ex
RoHS
RoHS Phthalates Compliant:Yes
RoHS
SVHC:No SVHC (04-Feb-2026)
Download Product Compliance Certificate
Product Compliance Certificate
Weight (kg):.000039
