Image is for illustrative purposes only. Please refer to product description.

| Manufacturer | MASCOT |
|---|---|
| Manufacturer Part No | 9970 24/12VCopy |
| Manufacturer Standard Lead Time | 12 weeks |
| Order Code | 1183946 |
| Product Range | 9970 Series |
| Your Part Number | |
| Technical Datasheet |
Available to Order
Manufacturer Standard Lead Time: 12 week(s)
Notify me when back in stock
| Quantity | Price |
|---|---|
| 1+ | Rs.18,894.750 |
| 5+ | Rs.18,516.860 |
| 10+ | Rs.18,138.960 |
Price for:Each
Minimum: 1
Multiple: 1
Rs.18,894.75
Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
Product Information
| Manufacturer | MASCOT |
|---|---|
| Manufacturer Part No | 9970 24/12VCopy |
| Manufacturer Standard Lead Time | 12 weeks |
| Order Code | 1183946 |
| Product Range | 9970 Series |
| Technical Datasheet | |
| Power Supply Applications | ITE |
| DC / DC Converter Type | - |
| Input Ratio | 2:1 |
| Output Power Max | 276W |
| No. of Outputs | 1 Output |
| Output Voltage - Output 1 | 13.8V |
| Output Current - Output 1 | 20A |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Output Regulation | Regulated |
| Isolation Voltage | - |
| Input Voltage DC Nom | - |
| DC / DC Converter Output Type | Fixed |
| Width | 102mm |
| Height | 63mm |
| Depth | 203mm |
| Input Voltage DC Min | 20V |
| Input Voltage DC Max | 30V |
| Product Range | 9970 Series |
| SVHC | No SVHC (14-Jun-2023) |
Product Overview
The 9970 24/12V is a 1-output 276W panel-mount DC/DC Converter Module features 90% efficiency and switch mode.
- Compact design
- Short circuit proof
- Terminal blocks (screw terminals)
Applications
Power Management
Technical Specifications
| Power Supply Applications | ITE |
|---|---|
| Input Ratio | 2:1 |
| No. of Outputs | 1 Output |
| Output Current - Output 1 | 20A |
| Output Current - Output 2 | - |
| Isolation Voltage | - |
| DC / DC Converter Output Type | Fixed |
| Height | 63mm |
| Input Voltage DC Min | 20V |
| Product Range | 9970 Series |
| DC / DC Converter Type | - |
|---|---|
| Output Power Max | 276W |
| Output Voltage - Output 1 | 13.8V |
| Output Voltage - Output 2 | - |
| Output Regulation | Regulated |
| Input Voltage DC Nom | - |
| Width | 102mm |
| Depth | 203mm |
| Input Voltage DC Max | 30V |
| SVHC | No SVHC (14-Jun-2023) |
Technical Docs (1)
Legislation and Environmental
| Country of Origin: Country in which last significant manufacturing process was carried outCountry of Origin: | China Country in which last significant manufacturing process was carried out |
|---|---|
| Tariff No: | 85389000 |
| US ECCN: | EAR99 |
| EU ECCN: | NLR |
| RoHS Compliant: | Yes RoHS |
| RoHS Phthalates Compliant: | Yes RoHS |
| SVHC: | No SVHC (14-Jun-2023) |
| Download Product Compliance Certificate | Product Compliance Certificate |
| Weight (kg): | 1 |
