MC33173
Resettable Fuse, PPTC, MP FRX, 90 VDC, 300 mA, 600 mA, 3 s, Round
Image is for illustrative purposes only. Please refer to product description.
| Manufacturer | MULTICOMP PRO |
|---|---|
| Manufacturer Part No | MC33173Copy |
| Manufacturer Standard Lead Time | 11 weeks |
| Order Code | 1800730 |
| Product Range | MP FRX |
| Your Part Number | |
| Technical Datasheet |
360 In Stock
Need more?
360 Delivery in 4-6 Business Days(UK stock)
| Quantity | Price |
|---|---|
| 10+ | Rs.17.580 |
| 50+ | Rs.13.630 |
| 100+ | Rs.11.420 |
| 250+ | Rs.10.500 |
| 500+ | Rs.9.560 |
Price for:Each
Minimum: 10
Multiple: 10
Rs.175.80
Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
Product Information
| Manufacturer | MULTICOMP PRO |
|---|---|
| Manufacturer Part No | MC33173Copy |
| Manufacturer Standard Lead Time | 11 weeks |
| Order Code | 1800730 |
| Product Range | MP FRX |
| Technical Datasheet | |
| Product Range | MP FRX |
| Voltage Rating | 90VDC |
| Holding Current | 300mA |
| Trip Current | 600mA |
| Time to Trip | 3s |
| Fuse Shape | Round |
| Current Rating Max | 40A |
| Lead Spacing | 5.1mm |
| Diameter | 7.4mm |
| Length | - |
| Thickness | 3.1mm |
| Height | 13mm |
| Operating Temperature Min | -40°C |
| Operating Temperature Max | 85°C |
| Automotive Qualification Standard | - |
| SVHC | To Be Advised |
Product Overview
MC33173 is a round, radial-leaded PPTC resettable fuse designed for 90V DC circuits. It provides reliable protection by holding 300mA during normal operation and tripping at 600mA in about 3 seconds, before automatically resetting once the fault clears, ideal for safeguarding low-current electronics in telecom, sensor, and industrial equipment.
- UL approved
- Self-resetting after overcurrent events provides uninterrupted circuit protection
- 300mA hold / 600mA trip (~3s response) gives fast fault reaction in low-current systems
- Withstands surge currents up to 40A, guarding against transient spikes
- Compact radial form integrates easily into dense PCBs
- Ensuring performance stability across varied environmental conditions
Technical Specifications
| Product Range | MP FRX |
|---|---|
| Holding Current | 300mA |
| Time to Trip | 3s |
| Current Rating Max | 40A |
| Diameter | 7.4mm |
| Thickness | 3.1mm |
| Operating Temperature Min | -40°C |
| Automotive Qualification Standard | - |
| Voltage Rating | 90VDC |
|---|---|
| Trip Current | 600mA |
| Fuse Shape | Round |
| Lead Spacing | 5.1mm |
| Length | - |
| Height | 13mm |
| Operating Temperature Max | 85°C |
| SVHC | To Be Advised |
Technical Docs (1)
Alternatives for MC33173
2 Products Found
Associated Products
4 Products Found
Legislation and Environmental
| Country of Origin: Country in which last significant manufacturing process was carried outCountry of Origin: | Taiwan Country in which last significant manufacturing process was carried out |
|---|---|
| Tariff No: | 85369090 |
| US ECCN: | EAR99 |
| EU ECCN: | NLR |
| RoHS Compliant: | Yes RoHS |
| RoHS Phthalates Compliant: | Yes RoHS |
| SVHC: | To Be Advised |
| Download Product Compliance Certificate | Product Compliance Certificate |
| Weight (kg): | .000187 |
