3916A.
IC TEST CLIP, 16POS, DIP, RED
Image is for illustrative purposes only. Please refer to product description.
19 In Stock
Need more?
19 Delivery in 4-6 Business Days(UK stock)
| Quantity | Price |
|---|---|
| 1+ | Rs.3,727.100 |
Price for:Each
Minimum: 1
Multiple: 1
Rs.3,727.10
Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
Product Information
Product Overview
Pomona DIP Clip test clips are designed for testing dual-in-line IC packages on PC boards. These devices incorporate many built-in features that assure a positive electrical connection as well as hands-free testing.
- Contacts (0.040" wide on lower end) are serrated for the best electrical contact
- 0.025"x0.028" serrated test points on upper end will accept wire wraps or mini test clips
- Moulded barriers between contacts allows live board connections without accidental shorting of contacts
- Can also be used as an insertion tool for DIPs
- Contacts are spring-tempered nickel silver
- Suitable for emulation, field service, failure analysis, and for use with logic analysers
Technical Docs (1)
Alternatives for 3916A.
1 Product Found
Associated Products
3 Products Found
Legislation and Environmental
Country of Origin:
Country in which last significant manufacturing process was carried outCountry of Origin:United States
Country in which last significant manufacturing process was carried out
Country in which last significant manufacturing process was carried outCountry of Origin:United States
Country in which last significant manufacturing process was carried out
Tariff No:85389000
US ECCN:EAR99
EU ECCN:NLR
RoHS Compliant:Yes
RoHS
RoHS Phthalates Compliant:To be advised
Download Product Compliance Certificate
Product Compliance Certificate
Weight (kg):.02268
