LS150-24
AC/DC Enclosed Power Supply (PSU), ITE, 1 Outputs, 150 W, 24 VDC, 6.5 A
Image is for illustrative purposes only. Please refer to product description.
| Manufacturer | TDK-LAMBDA |
|---|---|
| Manufacturer Part No | LS150-24Copy |
| Manufacturer Standard Lead Time | 40 weeks |
| Order Code | 1657463 |
| Product Range | LS Series |
| Your Part Number | |
| Technical Datasheet |
192 In Stock
240 more incoming. You can reserve stock now
192 Delivery in 4-6 Business Days(UK stock)
| Quantity | Price |
|---|---|
| 1+ | Rs.5,983.470 |
| 5+ | Rs.5,919.510 |
| 10+ | Rs.5,872.560 |
| 50+ | Rs.5,825.610 |
Price for:Each
Minimum: 1
Multiple: 1
Rs.5,983.47
Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
Product Information
| Manufacturer | TDK-LAMBDA |
|---|---|
| Manufacturer Part No | LS150-24Copy |
| Manufacturer Standard Lead Time | 40 weeks |
| Order Code | 1657463 |
| Product Range | LS Series |
| Technical Datasheet | |
| Power Supply Applications | ITE |
| No. of Outputs | 1Outputs |
| Output Power Max | 150W |
| Output Voltage - Output 1 | 24VDC |
| Output Current - Output 1 | 6.5A |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Output Voltage - Output 4 | - |
| Output Current - Output 4 | - |
| Input Voltage VAC | 88V AC to 264V AC |
| Power Supply Output Type | Adjustable, Fixed |
| Product Range | LS Series |
| SVHC | No SVHC (27-Jun-2024) |
Product Overview
The LS150-24 from TDK Lambda is a single output, 150W AC to DC power supply. It complies with UL60950-1, EN60950-1, IEC60950-1, CE mark safety standards.
- Input voltage range from 88VAC to 132VAC/176VAC to 264VAC
- Output voltage is 24VDC
- Output current is 6.5A
- Efficiency is 86%
- Withstands 300VAC surges
- Dimension is 7.8mm x 3.9mm x 1.5mm
Applications
Power Management, Industrial, Communications & Networking
Technical Specifications
| Power Supply Applications | ITE |
|---|---|
| Output Power Max | 150W |
| Output Current - Output 1 | 6.5A |
| Output Current - Output 2 | - |
| Output Current - Output 3 | - |
| Output Current - Output 4 | - |
| Power Supply Output Type | Adjustable, Fixed |
| SVHC | No SVHC (27-Jun-2024) |
| No. of Outputs | 1Outputs |
|---|---|
| Output Voltage - Output 1 | 24VDC |
| Output Voltage - Output 2 | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 4 | - |
| Input Voltage VAC | 88V AC to 264V AC |
| Product Range | LS Series |
Legislation and Environmental
| Country of Origin: Country in which last significant manufacturing process was carried outCountry of Origin: | Malaysia Country in which last significant manufacturing process was carried out |
|---|---|
| Tariff No: | 85045090 |
| US ECCN: | EAR99 |
| EU ECCN: | NLR |
| RoHS Compliant: | Yes RoHS |
| RoHS Phthalates Compliant: | Yes RoHS |
| SVHC: | No SVHC (27-Jun-2024) |
| Download Product Compliance Certificate | Product Compliance Certificate |
| Weight (kg): | .7 |
