TDK-LAMBDA LS75-24
AC/DC Enclosed Power Supply (PSU), ITE, 1 Outputs, 76.8 W, 24 VDC, 3.2 A
- Manufacturer:
- TDK-LAMBDA TDK-LAMBDA
- Manufacturer Part No:
- LS75-24
- Order Code:
- 1657447
-
- Product Range
- LS Series
- Technical Datasheet:
- LS75-24 Datasheet
- ECAD / MCAD
-
Product Range Selector (LS Series)
See all from this product rangeProduct Information
Want to see similar products? Simply select your required attributes below and hit the button ×
- :
- ITE
- :
- 1Outputs
- :
- 76.8W
- :
- 24VDC
- :
- 3.2A
- :
- -
- :
- -
- :
- -
- :
- -
- :
- -
- :
- -
- :
- 88V AC to 264V AC
- :
- Adjustable, Fixed
- :
- LS Series
Technical Documents (2)
Product Overview
The LS75-24 is a 24V/75W 1-output enclosed Power Supply is an economical and environmental-friendly, high efficiency power output will reduce the amount of wasted energy. Strict evaluation of components used will also reduce defect. Low and high voltage full line up, LS-series cover most of the output voltage to cater wide range of applications. The available 36V is suitable for applications like printer head or LED display panel. Compact size, smaller than current model in which can give more flexibility in design. This compact design is ideal for application including indoor display, self service kiosk and vending machines. Wide operating temperature, designed to operate reliably between -25 to 50°C at 100% load and up to 70°C at derated load. This feature is the best solution for equipment to run in extreme environments. This power supply output is fixed.
- 86% Efficiency
- 120mVp-p Maximum ripple and noise
- -25 to 70°C Operating temperature range
Applications
Computers & Computer Peripherals, Communications & Networking, Test & Measurement, Consumer Electronics
Warnings
Do not modify. Do not touch the internal components, they may have high voltage or high temperature. When the unit is operating, keep hands and face away from it. Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
54 In stock Need more?
×
You can reserve stock now just order your desired quantity and checkout as normal. The quantity that cant be dispatched now will be placed on back order and sent as soon as we get a delivery from our supplier.
60 more will be available on 27/1/24
40 more will be available on 14/2/24
20 more will be available on 20/4/24
Extra stock is available upon order to the Supplier Lead Time which is approximately 8/7/24
24 SG stock available for 3-5 business days delivery
30 UK stock available for 4-6 business days delivery
30 UK stock available for 4-6 business days delivery
Due to market conditions delivery times are for general guidance only and may be subject to change at short notice
